System IP

Pentaplex function Live view / recording / playback / archiving / remote access

Channels 4

HDD support 1

HDD capacity 6 TB

Max recording resolution 8 Mpx

System IP

Pentaplex function Live view / recording / playback / archiving / remote access

Channels 10

HDD support 1

HDD capacity 6 TB

Max recording resolution 8 Mpx

• Display and record 4 IPC with max resolution 8Mpx

• Compression H.265+/H265/H.264+/H.264

• Max incoming bandwidth 40Mbps, outgoing 80Mbps

• Synchronous HDMI4K(3840×2160) and VGA(1920×1080)

• Advanced video detection: motion detect, crossline, intrusion

• Support 1 HDD SATA up to 6TB

• 1 audio in / 1 audio out

• 2×USB, 1×RJ45

• Built-in 4 port switch PoE 50W

• Built-in web service, support CMS(BCS Manager), mobile app BCS(android, iOS), P2P, Onvif

• Power supply DC 48V

System IP

Pentaplex function Live view / recording / playback / archiving / remote access

Channels 8

HDD support 1

HDD capacity 6 TB

Max recording resolution 8 Mpx
Switch PoE power 75W max 30W/port

PoE channels 8

Power supply 52V DC
